Con un diseño de caja de gran volumen, el Subwoofer de estudio Sub 6 está equipado con un woofer de 11 pulgadas y un tubo bass-reflex trasero.
Esta configuración garantiza la linealidad en graves, independientemente del nivel de presión sonora. En cuanto a conectividad, acepta conexiones en 2.1, 2.2 y multicanal, por medio de sus entradas y salidas L/R y LFE. Sus varias posibilidades de ajustes, tales como el crossover paso-alto, posibilidad de ajustar la fase y control de nivel, proporcionan el acoplamiento necesario con los monitores Solo6 Be y Twin6. Por último, una característica en principio irrelevante pero ciertamente importante: su entrada para conectar un pedal, la cual permite activar y desactivar el subgrave y los crossovers paso-alto en las salidas que poseen los monitores, lo que simplifica (y al mismo tiempo mejora) el trabajo durante las diferentes fases del monitoraje.
The Sub6 is an active subwoofer (1 x 350W RMS built-in amplifier - BASH technology) for professional monitoring systems. The driver is an 11" Focal with a "W" sandwich composite cone loaded by a large section laminar port. It can be used both as LFE channel in a surround system or as a bass or sub-bass complement in a stereo system (2.1 or 2.2). The Sub6 was designed to permit optimum acoustic coupling with professional monitoring speakers. Therefore, it includes all the features to achieve this task, such as stereo high pass filter (75 or 100Hz) for the left and right satellites, low pass filter (adjustable) with mono summation, phase inverter, phase fine tuning, mute switch, 2.1 bypass with a footswitch remote control (not included), as well as a wiring panel rich in possibilities.
• The “W” cone Focal has been developing the technologies of composite sandwich cones for more than 15 years. The "W" process (Glass/Foam/Glass), used on the SM11, SM8 and SM6 lines, provides a true optimiza a true optimization of the frequency response by fine tuning of mass, rigidity and damping parameters. The balance between these 3 fundamental and often contradictory parameters is at the base of the outstanding sound neutrality of our speakers. The 105/8"(27cm) Focal speaker is equipped with a high excursion system to enable accurate and extended reproduction in the bass/ infra bass register. The 25/8" (66mm) diameter and 11/4" (32mm) height voice coil ensures a perfect mechanical coupling and a total control of the driver even at high sound level. The magnetic construction made of double ferrite and large field and back plates offers high symmetrical magnetic field to keep dynamics even at very low frequency.
• A custom designed amplification stage Designing an amp to be integrated inside a speaker requires a very different set of rules than for a traditional amp. Speaker size and cooling concerns are often in contradiction with the high quality and high power requirements of a sonically transparent speaker. Our engineers used the BASH® technology to develop the bass/medium amplification circuit for the SM6 professional line of speakers. This was the only way to exploit the best of class AB style circuits (for exceptional quality) with a class D type yield, which is crucial when housing a 150W RMS circuit in such a small space (300W RMS for the Twin6 Be and 350W RMS for the Sub6).
Specifications:
- Provides bass reinforcement for the Solo6 Be and Twin6 Be studio monitors
- 11" "W" composite sandwich cone driver is housed in a high-volume MDF cabinet
- Cabinet has a rear laminar bass port, which helps extend bass response all the way down to 30Hz
- Right, left, and LFE balanced XLR inputs for connecting to pro-level audio systems
- 1/4" footswitch input allows you to connect a pedal for hands-free control
- Signal treatment and control options include mono left/right summation, phase adjustment, polarity switch, high/low pass filters, level control, muting, and bypass
-
Technical specs:
| Low Frequency Driver |
11" (279mm) "W" Composite Sandwich Cone Woofer |
| Amplifier |
350W RMS BASH |
| Crossover |
Not Specified by Manufacturer |
| Frequency Range |
30-250Hz |
| Maximum Sound Pressure Level (SPL) |
116dB (Peak) |
| Connectors |
3 x Balanced XLR Inputs
2 x Balanced XLR Outputs 1 x 1/4" Footswitch Input
1 x Power Input |
| Input Impedance |
10 kOhms |
| Controls and Indicators |
1 x Power Switch
1 x Voltage Selector Switch
1 x Level Control Knob
1 x Phase Knob
1 x Low Pass Knob
2 x High Pass Switches
1 x Polarity Switch
1 x Mute Switch
1 x Power LED
1 x Mute LED
1 x High Pass LED |
| Shielded |
No |
Dimensions (HxWxD) 14.9 x 13.6 x 17.3" (380 x 344 x 440mm)
Weight 50.7 lbs (23kg)
Packaging Info
Package Weight 58.35 lb
Box Dimensions (LxWxH) 22.5 x 22.0 x 18.0"
